Vacuum drying oven
Model: Vacuum drying oven VDL056-230V-EU with Pump
chamber and Vacuum pump VAP 5 (BINDER)
Person responsible: Dr. Špela Kunej
Vacuum drying oven:
For flammable
solvents, Explosion protected unit with classification according to ATEX
directive 2014/34/EU: EX II 2/3/- G IIB T3 Gb/Gc/- X
- Temperature range above ambient+9 °C to 110°C
- Interior volume 56L
- Program-controlled drying monitoring with automatic ventilation at end of process
- Pressure control device for heating activated from < 100 mbar
- Universal connection for ventilation with ambient air or inert gas
Pump chamber:
The pump module reduces the
noise of the vacuum pump and protects the pump and glass material from
mechanical damage
Vacuum pump VAP 5:
ATEX chemical membrane pump, Vacuum drying of
flammable solvents up to an ignition temperature of 200°C, and non-flammable
solvents
- Operation with BINDER series VDL vacuum
drying chamber
- Nominal airflow 3.9 m3/h
- End vacuum < 2 mbar
- Noise level < 50 dB(A)
- Designed for continuous operation
- Resistant to numerous chemicals
